4 giriş 4 çıkış VGA Matrix Seçici (VGA Matrix Switch)

Ürün Açıklaması

Connects any of four VGA Video + Audio inputs to any of four VGA Video + Audio outputsLong distance transmission – up to 30mEasily switch between multiple sources and multiple displaysEasy Operation: • Front panel pushbuttons • RS-232 serial controllerSuperior video quality – up to 1920 x 1440; VGA, SVGA, XGA, SXGA, UXGA, and WUXGA (1920 x 1200)Supports up to 300 MHz bandwidth for high performance videoEDID Expert – selects the optimum EDID settings for smooth power-up and highest quality displayBuilt-in bi-directional RS-232 serial port for high-end system control*Independent switching of audio and video sources – each input can be independently connected to any or all outputs for flexibilityRack Mountable Video InputInterfaces4 x HDB-15 Male (Blue)Impedance75 ?Max. Distance1.8 mVideo OutputInterfaces4 x HDB-15 Female (Blue)Impedance75 ?Max. Distance30 mVideoMax. Bandwidth300 MHzMax. ResolutionUp to 1920 x 1200Max. DistanceUp to 30 mAudioInput4 x Mini Stereo Jack Female (Green)Output4 x Mini Stereo Jack Female (Green)ControlRS-232Connector: 1 x DB-9 Female (Black)Baud rate and protocol:Baud Rate: 19200, Data Bits: 8, Stop Bits:1, Parity: No, Flow Control: NoIR1 x Mini Stereo Jack Female (Black)EDID SettingsEDID Mode: Default / Port1 / Remix / AutoPowerConnectors1 x DC Jack (Black)Consumption5.3 VDC, 2.7WEnvironmentalOperating Temperature0-50°CStorage Temperature-20 - 60°CHumidity0 - 80% RH, Non-CondensingPhysical PropertiesHousingMetalWeight0.87 kg ( 1.92 lb )Dimensions (L x W x H)26.00 x 7.61 x 4.40 cm(10.24 x 3 x 1.73 in.)Carton Lot5 pcs Package Contents1x VM0404 4x4 Video Matrix Switch with Audio1x Power Adapter1x User Instructions
