Afox IH61-MA5-V6 Sc-1155 DDR3 1600Mzh M.2 GEn3 VGA HDMI MATX INTEL Anakart

Ürün Açıklaması

Afox IH61-MA5-V6 Sc-1155 DDR3 1600Mzh M.2 GEn3 VGA HDMI MATX INTEL Anakart latformINTEL® Socket 1155Model NameIH61-MA5-V6ChipsetIntel® H61CPU SupportsIntel Core™ i7 / Core™ i5 / Core™ i3 / Pentium® / Celeron® Processors FSB1066 / 1333 / 1600MHzMemoryDual Channel DDR3 1066 / 1333 / 1600MHzDimm2 x Memory Slots (Max. capacity of system memory 16GB)Onboard GraphicsIntegrated Graphics ProcessorPCI/PCI-E Slots1 x PCI Express x16 slot1 x PCI Express x1 slotSATA3 x SATA3, 1 x M.2 (PCIe NVMe Gen3 x4 & SATA3)IDEN/AAudioRealtek 662 on board, Supports 6-channel audio-outLANRealtek RTL8111 Gigabit Ethernet on boardBack Panel I/Os1 x HDMI Port1 x D-Sub (VGA) Port6 x USB 2.0 Ports1 x RJ-45 LAN Port3 x HD Audio Jacks (Line in / Front Speaker / Microphone)ON-Board Pinheaders/Connectors1 x USB 2.0 pinheader (supports additional 2 USB 2.0s)1 x USB 3.0 pinheader (supports additional 2 USB 2.0s)1 x Front Panel Audio pinheader 1 x LPC DEBUGBIOSUEFI BIOSForm FactorMicro-ATX (17*21.5cm)Mounting4 mounting holesAccessories1 x SATA II cable1 x I/O Rear Panel1 x User Manual1 x Driver CD
