Scotsman MF 46 Haznesiz Kar Buz Makinesi

Ürün Açıklaması

• Hermetic compressor. Stainless steel auger and freezing cylinder (evaporator). Equipped with an electronic control board.• Ice breaker made in specially strengthened alloy, allowing for greater extrusion pressure to deliver a dryer-quality of ice (85% dry).• Long-lasting stainless steel ball-bearings. Double protection - electronic rotation sensor and drive coupling - on gear motor and gear reducer.• Low-water sensor protection on refrigeration and gear motor system. Optical ice level sensor for machine shut down.• Stainless steel side panels in scotch-brite finish, with rounded corners for enhanced ease of cleaning and aesthetics.• Side panels are removable on all four sides to ease maintenance and after-sales service operations.• PS plastic top cover.• Reduced height to ease installation.MF 46 Superflake ice Residual water content 15%REFRIGERANT GAS R404AVOLTAGE V/Hz/ph 230/50/1 230/60/1OPERATING REQUIREMENTSMinimum MaximumAir temperature 10°C / 43°CWater temperature 5°C / 38°CWater pressure 1 bar (14 psi) / 5 bar (70 psi)Electrical voltage -10% / +10%Condensing system: Air cooled, Water cooled Max daily production: 320 kg (referred to the standard model)Dimensions without legs: W 538 mm D 663 mm H 645 mmDimensions with legs: W 538 mm D 663 mm H 645 mm
